NAP-8227(SR)

     NAP-8227 (SR), an outdoor wireless access point developed by Sundray, represents the latest generation of high-performance solutions. It supports the Wi-Fi 7 (802.11be) standard with advanced features including 4096-QAM, Multi-Link, and Multi-RU, delivering ultra-fast, reliable, and low-latency connectivity. Featuring a triple RF six-space stream design, it achieves speeds up to 4.437Gbps, meeting the high-performance demands of video conferencing, VR/AR, and 8K video applications. The device also integrates a dedicated AI chip that combines five sensing capabilities: wireless environment awareness, authentication quality monitoring, network quality assessment, service quality evaluation, and edge security detection.

Specification

  • Product Model

    NAP-8227(SR)

  • Size and Weight

    Size:242*242*74mm

    Weight:2.36Kg

  • Operating Frequency Band

    802.11be/ax/ac/n/a: 5.725GHz-5.850GHz; 5.15~5.35GHz (China)

    802.11be/ax/b/g/n: 2.4GHz-2.483GHz (China)

  • Service port

    1*10G optical port, 1*2.5G electrical port

  • Working/storage temperature and Working/Storage Humidity

    Working/storage temperature:-40℃~70℃

    Working/Storage Humidity:5% to 95% (non-condensed)

  • Maximum Number of Connected Users

    512

  • Antenna

    Equipped with two independent high-gain antennas for directional and omnidirectional operation, enabling flexible switching

  • Transmission Power

    2.4G:27dBm 5.2G:23dBm 5.8G:33dBm

Product Value

Safety

Comprehensive Security Protection for User Network Access


Smart

Safeguarding the Network with AI Intelligence


Ultimate Experience

Enjoying an Exceptional Internet and Network Management Experience
